Machinery Diagnostics - Module 02

Introduction:

This training will equip participants to operate the Machinery Diagnostic System for real-time data collection, interpret diagnostic plots, select suitable plot formats for various diagnostic stages, and identify common machine faults such as unbalance, misalignment, rubs, cracks, and fluid issues.

Objective:

• Learn to use ADRE system for efficient real-time data collection
• Use the diagnostic plots to display critical data such as vibration and position data
• Explain which plot formats are best to use in the different stages of machine diagnostics
• Recognize problems such as unbalance; misalignment; rubs; shaft cracks and fluid

Who Should Attend:

• Engineers / Technicians who use ADRE 408 system for data acquisition
• Engineers who interpret machine vibration and position data to determine machine condition
• Engineers interested in learning about machinery vibration diagnostics.

Contents:

• Fundamentals of Synchronous Rotor Response
• Diagnostic Plot Interpretations
• Vibration types and resonances
• Preloads and radial position measurements
• Detection and identification of rubs
• Identification of fluid-induced instabilities
• Fluid film bearing characteristics & use of shaft centerline plots
• Detection and identification of shaft-crack-induced instabilities
